Ribble CGR AL Blue - Sram Apex 1x 650B

Ribble CGR AL Blue - Sram Apex 1x 650B
CGR-AL Blue - Sram Apex 1x
Apex

THE RIBBLE CGR AL - SRAM APEX 1X

US$1,258.25
Finance & Cycle to Work schemes available
HOW TO BUY
PERFECT COMBO OF SRAM APEX 1X & ALUMINIUM

For maximum off road capability we have chosen Srams Apex 1x groupset and Mavics Aksium 650b wheels. The lack of front derailleur means that it eliminates any chance of front mech failure due to the mech being clogged up with mud. The 650b wheels are perfect for wider tyres ensuring great grip and traction when off road.

  • Groupset
    SRAM Apex 1 x Hydraulic
  • Wheels
    Mavic Aksium Elite 650b
  • Bars & Stem
    Level Alloy 1
  • Saddle
    WTB Koda Race 142mm
From US$40.96 a Month
US$1,258.25
CYCLE TO WORK SCHEMES AVAILABLE
FULL SPECIFICATION

THE CGR ALLOY SRAM APEX 1x HYDRAULIC

With Srams rather unique ‘double tap ‘system where one small push of the lever blade shifts up the cassette and a longer press shifts down Sram states that’ this offers intuitive one handed shifting’.

The CGR alloy is designed to excel both on and off road thanks to its versatility and wide range of tyre clearance plus the additions of mudguards and rack mounts.

Groupset

  • SRAM Apex 1x Hydraulic
    • Shifters - Apex 1 HRD
    • Brakes - Apex 1 Post Mount Hydraulic
    • Chainset - FSA Omega 42T
    • Bottom Bracket - Sram GXP Team BSA 68mm
    • Cassette - Sram PG-1130 11/42T
    • Chain - Sram PC1130 with Powerlock
    • Front Derailleur - N/A
    • Rear Derailleur - Apex 1 Long Cage
    • Rotors - Centrelock 160mm

Wheelset

  • Wheels - Mavic Aksium Elite Disc 650b,Clincher 12mm Thru-Axle
  • Tyres - WTB Horizon Road Plus 650x47c, Tan Wall

Finishing Kit

  • Bars - Level 1 Alloy, Black
  • Stem - Level 1 Alloy, Black
  • Bar Tape - Level bar Ribbon, Black
  • Seatpost - Level 1 Alloy 27.2mm, 350mm, Black
  • Saddle - WTB Koda Race 142mm, Black

Finance Calculator


%
Total amount repayable .
APR representative.

Finance is subject to status. Terms and conditions apply.

How much does the CGR AL weigh??

The 6061 T6 heat treated frame weighs 1680g and the carbon fork 470g (+/-5g).

What is the warranty of the frame?

The frame has a year 3 warranty against manufacturing defects. All other parts have the manufacturer's standard warranty.

What is the maximum width of tyre that can be fitted to the CGR AL?

Without full mudguards the CGR Alloy can accommodate tyres up to 45mm width or 40mm if fitted with full mudguards (700c wheels). Wider tyres are particularly suitable if you want to ride over rougher roads or gravel and with 650b wheels there is room for 47mm wide tyres.

What type of riding is it best suited for?

The CGR Alloy is designed to be extremely versatile so is ideal for fast commuting, bike touring or bikepacking, gravel riding and all forms of road riding. The sporty, endurance ( relaxed position ) geometry allows you to achieve a perfect position to get where you want to.

How many bottle cage mounts are there on the CGR Alloy?

The CGR Alloy has 3 pairs of bottle cage mounts on the seat tube, down tube and on the underside of the down tube.

How much is the CGR AL able to carry on a rear fitted pannier rack?

The CGR AL is capable of carrying up to 20kg on a traditional pannier rack.

What is the maximum rider weight for the CGR AL?

120kg.

Can I fit mudguards with 650b wheels?

Yes, just like with 700c wheels the 47mm tyres will are also compatible with wide fitting mudguards.

Does the bike come with pedals?

No, pedals are a personal choice. We do however offer a wide range of pedals to be bought separately to suit all preferences.

SHOW ALL

Sizing & Geometry

Ribble CGR AL Blue - Sram Apex 1x 650B
Size XS S M L XL
Rider Height 5'4 - 5'7
162 - 170cm
5'7 - 5'9
170 - 175cm
5'9 - 5'11
175 - 180cm
5'11 - 6'1
180 - 185cm
6'1 - 6'4
185 - 194cm
A 74.5° 74.0° 73.5° 73.0° 72.5°
B (mm) 520 540 555 570 590
C 70.5° 71.0° 71.5° 72.0° 72.0°
D (mm) 50 50 50 50 50
E (mm) 140 150 170 190 200
F (mm) 69 69 69 69 69
RC (mm) 435 435 435 435 435
FC (mm) 595 605 611 616 630
Stack (mm) 556 568 589 610 620
Reach (mm) 365 377 380 383 395
WB (mm) 1021.5 1031 1036.8 1041.8 1055
G (mm) 470 510 530 555 580
  • Groupset
    SRAM Apex 1 x Hydraulic
  • Wheels
    Mavic Aksium Elite 650b
  • Bars & Stem
    Level 1 Alloy
  • Saddle
    WTB Koda Race 142mm
From US$40.96 a Month
US$1,258.25
CYCLE TO WORK SCHEMES AVAILABLE

Ribble CGR AL Blue - Sram Apex 1x 650B Customer Reviews

Got the Blue CGR AL with SRAM Apex 1x, Mavic Allroads and Schwalbe G-One tires. Used a cyclescheme voucher and paid the difference. The bike is beautiful, looks better in person that in the picture. Rides very nice. I am 1.75m tall, so right in between S and M sizes. I've got the M, but now think perhaps the S would have been better (it's always easier to extend the fit on a smaller bike than the opposite). But it may also be that I am out of shape after several years without cycling. I found the 1x system excellent for commuting, and haven't felt any lack of gearing or been bothered by the larger "jumps" between gears. If you're not riding at top performance, it probably won't matter to you. Haven't had a chance to try it on gravel yet.

My only gripe with the bike itself is that the top tube has a triangular cross-section near the junction with the seat tube, making the bike very uncomfortable to shoulder-carry. Also, make note that the Schwalbe One-G Allround with the classic skin-colored sidewall IS NOT TUBELESS compatible (https://www.schwalbe.com/en/offroad-reader/schwalbe-g-one-allround.html). I bought it as an upgrade together with the Mavic Allroad rims with the intention of riding tubeless, but nope. It would be good to add a warning in the build site, and/or offer the regular, black tubeless version as an option as well.

Shipping took a bit longer than expected, and tracking it on the site was of no use (order is still in "processing" to this day). I also got the bike bundle, which at the time included a small cafe lock. After receiving the package without it and inquiring, was told that their discontinued the cafe lock and was refunded 5 pounds. Also, the cleaning supply bottles were packaged with everything else, and leaked during shipping, getting all over the other components. Luckily it didn't get into the disk breaks or the bar tape.

Overall, the bike itself is great and one of the best values around (believe me I had a spreadsheet with 20+ models - I have a problem), but the building site could include better information about the components, and the shipping and packing could get a bit more love.

And if you do get this bike, do yourself a favor and pay the small extra fee for the color-detailed seat and two-tone bar tape. It looks awesome!
Thiago Silva
The new CGR gravel bike is well balanced and extremely comfortable. Looking forward to taking it off the beaten track. Once again another quality made bike by Ribble.
Graham

Review 1 to 2 of 4 total
