Ribble Gravel SL - Enthusiast
SRAM Rival XPLR eTap AXS

BBGRAVSL006
From: US$3,264.58
This is a loan of US$3,917.50 with US$0.00 deposit.
Repayable by 36 monthly repayments of US$133.82.
Total amount repayable US$4,817.67.
14.9 APR representative.
Finance is subject to status. Terms and conditions apply.
Or from: US$133.82 a month
Also available on Cycle To Work schemes
Image is for illustration purposes only and features upgrades that are available in the BikeBuilder.
The upgrades are:
  • LEVEL 5 carbon integrated flared gravel handlebar system
  • WTB Sendero tyres
An image of the Ribble Gravel SL - Enthusiast SRAM Rival XPLR eTap AXS
THE EVOLUTION
OF GRAVEL

Flowingly fast and astonishingly agile, the Gravel SL strikes the perfect balance between everyday off-road explorer and race-ready gravel crusher. This high-performance build includes the incredibly wide-range gearing and fully wireless electronic gear shifts of a SRAM Rival XPLR eTap AXS 1x12 speed system, lightweight yet robust Mavic Allroad 650b wheels fitted with traction enabling Halo GXC Gravel 650bx47mm tyres and the gravel-optimised ergonomics of the LEVEL flared gravel riser handlebars. The Gravel SL delivers an unmatched ride experience that's made for those extreme off-road adventures, large or small.

  • Material

    Toray T1000/T800 Carbon Monocoque

  • Groupset

    SRAM Rival XPLR eTap AXS

  • Wheels

    Mavic Allroad 650B Alloy Disc

  • Brakes

    SRAM Rival Hydraulic Disc

GROUPSET

SRAM Rival XPLR AXS lets you equip your gravel bike with the most sought-after features and technologies. This 1x12 speed gear system combines a dedicated 1x specific rear derailleur with a massive 440% gear range to provide smooth gear progression as you fly up technical climbs and tighter gear steps for when its time to put the hammer down on singletrack descents. AXS connectivity allows you to fully customise component behaviour, personalise controls, check battery status and update firmware, all form one device. Rival XPLR is fully interchangeable with the entire AXS ecosystem and includes the powerful and predictable braking control of hydraulic disc brakes.

Groupset
WHEELSET

Mavic Allroad is a supremely capable multi-terrain wheelset that features a wide rim profile and 650b diameter to help you tackle the roughest roads, pave, gravel, or dirt with speed, control, and a dynamic ride quality. Fitted with the aggressive, all-weather Halo GXC Gravel 650bx47mm tyres for surefooted traction and control when playing in the dirt or lighting it up on the loose stuff.

Wheelset
FLARED BARS

LEVEL Gravel Riser handlebars have been developed specifically for gravel riding, a 20mm rise offers multiple hand positions and more space on the bars when running a barbag. Flared drops provide a wider, more stable stance for improved handling and control when descending and navigating technical terrain. The handlebars are wrapped in a vibration absorbing LEVEL embossed bar tape and are neatly matched with a LEVEL 2 3D forged alloy handlebar stem.

Handlebars
SADDLE

A lightweight and aerodynamic SL Carbon seat post fitted with a Fizik Taiga saddle soak up the vibrations from uneven surfaces for enhanced comfort and support. A wide selection of saddles to suit riders of all shapes and sizes is also available in Bike Builder.

Saddle
Custom Colour
Available

You decide the design, we create the bike. Be bold and bright or stealthy as you like. With millions of combinations, you can make a bike unique to you.

Just select customise after choosing your size.

Your Bike. Your Way
Size
Guide

To assist you in selecting the correct size simply find you height below. The graphic below illustrates our recommendations so you can be confident that the size you order will be correct.

X-Small
5' 4" - 5' 7"
162cm - 170cm
Small
5' 7" - 5' 9"
170cm - 175cm
Medium
5' 9" - 5' 11"
175cm - 180cm
Large
5' 11" - 6' 1"
180cm - 185cm
X-Large
6' 1" - 6' 4"
185cm - 194cm
View Full Sizing & Geometry
Sizing &
Geometry
Ribble Gravel SL - Enthusiast
Size XS S M L XL
Rider Height 5'4" - 5'7"
162 - 170cm
5'7" - 5'9"
170 - 175cm
5'9" - 5'11"
175 - 180cm
5'11" - 6'1"
180 - 185cm
6'1" - 6'4"
185 - 194cm
Wheel Size 650b / 700c 650b / 700c 650b / 700c 650b / 700c 650b / 700c
A - Seat Angle (mm) 74.5° 74° 73.5° 73° 72.5°
B - Top Tube (mm) 520 540 555 570 590
C - Head Angle (mm) 70.5° 71° 71.5° 72° 72°
D - Offset (mm) 50 50 50 50 50
E - Head Tube (mm) 130 140 155 180 200
F - BB Drop (mm) 69 69 69 69 69
G - Seat Tube (mm) 460 480 500 520 540
RC - Chainstay (mm) 435 435 435 435 435
FC - Front Centre(mm) 593 599 600.7 615.5 616
Reach (mm) 371 375 379 389 396
Stack (mm) 537 548.5 561 592 610.7
WB - Wheelbase (mm) 1019 1025 1025 1041 1054
Available on
Cycle To Work

The Ribble Gravel SL - Enthusiast is available to order on cycle to work schemes.

We accept all major cycle to work scheme vouchers.

Cyclescheme logos
Full
Specification
Groupset
SRAM Rival AXS XPLR 1x12 Speed Hydraulic Disc
Shifters - SRAM Rival eTap AXS 12 Speed.
Brakes - SRAM Rival eTap AXS Hydraulic disc.
Chainset - SRAM Rival D1 DUB 1x12 Speed, 40T.
Bottom Bracket - SRAM DUB Threaded BSA.
Cassette - SRAM XG1251 D1 XPLR 12 Speed 10-44T.
Chain - SRAM Rival D1 12-Speed with Powerlock.
Rotors - SRAM Centreline XR Centre Lock 160mm.
Rear Derailleur - SRAM Rival XPLR eTap AXS D1 Max 44T.
Wheelset
Wheels - Mavic Allroad Disc 650b, 12x100F/12x142R, Thru-Axle.
Tyres - Halo GXC Gravel, 650bx47mm, Tan Wall.
Frameset
Frame - Toray T800/T1000 Carbon Fibre Monocoque.
Forks - Gravel SL, Full Carbon, Tapered Steerer, Carryall Mounts.
Headset - Ribble SL, 1.5”x1.5” Top and Bottom, Black.
Finishing Kit
Bars - LEVEL Gravel Riser Flared Alloy, 420/510mm.
Stem - LEVEL 2 3D-Forged 6061 Alloy, Black.
Bar Tape - LEVEL Embossed, Black.
Seatpost - Ribble SL Carbon with 5mm Offset.
Saddle - Fizik Taiga S-Alloy Rails, Black.
Frame Protection - Ribble Frame Protection Kit, Clear.
