Bikes Gravel Bikes CGR Range CGR AL

Ribble CGR AL Orange
Shimano Tiagra

From: US$1,009.83
Or from US$34.12 a month
An image of the Ribble CGR AL Orange  Shimano Tiagra
PERFECT COMBO OF
TIAGRA & ALUMINIUM

This combination of the Shimano Tiagra groupset and Mavic Aksium wheelset is a tried and tested combination. For a bike that offers great versatility with precise gear changes and reliability over any terrain then this is a great choice. The CGR alloy is designed to excel both on and off road thanks to its versatility and wide range of tyre clearance plus the additions of mudguards and rack mounts.

Size
Guide

To assist you in selecting the correct size simply find you height below. The graphic below illustrates our recommendations so you can be confident that the size you order will be correct.

X-Small
5' 4" - 5' 7"
162cm - 170cm
Small
5' 7" - 5' 9"
170cm - 175cm
Medium
5' 9" - 5' 11"
175cm - 180cm
Large
5' 11" - 6' 1"
180cm - 185cm
X-Large
6' 1" - 6' 4"
185cm - 194cm
View Full Sizing & Geometry
Sizing &
Geometry
Ribble CGR AL Orange
Size XS S M L XL
Rider Height 5'4" - 5'7"
162 - 170cm
5'7" - 5'9"
170 - 175cm
5'9" - 5'11"
175 - 180cm
5'11" - 6'1"
180 - 185cm
6'1" - 6'4"
185 - 194cm
Wheel Size 650b / 700c 650b / 700c 650b / 700c 650b / 700c 650b / 700c
A - Seat Angle (mm) 74.5° 74° 73.5° 73° 72.5°
B - Top Tube (mm) 530 545 555 570 590
C - Head Angle (mm) 70.5° 71° 71.5° 72° 72°
D - Offset (mm) 50 50 50 50 50
E - Head Tube (mm) 140 150 170 190 200
F - BB Drop (mm) 69 69 69 69 69
G - Seat Tube (mm) 470 510 530 555 580
RC - Chainstay (mm) 435 435 435 435 435
FC - Front Centre(mm) 595 605 611 616 630
Reach (mm) 365 377 380 383 395
Stack (mm) 556 568 589 610 620
WB - Wheelbase (mm) 1021.5 1031 1036.8 1041.8 1055
Available on
Cycle To Work

The Ribble CGR AL Orange is available to order on cycle to work schemes.

We accept all major cycle to work scheme vouchers.

Cyclescheme logos
Full
Specification
Groupset
Shimano Tiagra 4700 10 Speed Mechanical Disc
Shifters - Tiagra 4700 STI's 10 Speed
Brakes - Tektro MD510 Mechanical Disc
Chainset - Tiagra 4700 34-50T
Bottom Bracket - Shimano BB-RS500 BSA
Cassette - Shimano HG500 11-32T
Chain - Shimano HG54 10 Speed
Rotors - Centrelock 160mm
Front Derailleur - Tiagra 4700 Braze On
Rear Derailleur - Tiagra 4700 Med Cage
Wheelset
Wheels - Mavic Aksium Disc Clincher, 12mm Bolt Thru-Axle
Tyres - Continental Ultra Sport 2 700x28c, Black
Frameset
Frame - 6061 T6 Heat Treated Aluminium.
Forks - Full Carbon Fibre Monocoque.
Finishing Kit
Bars - Level 1 Alloy, Black
Stem - Level 1 Alloy, Black
Bar Tape - Level Cork Ribbon, Black
Seatpost - Level 1 Alloy 27.2mm, 350mm, Black
Saddle - Prologo Kappa RS, Black
Buy
Now
Buy Now
From: US$1,009.83
Or from US$34.12 a month and available on Cycle To Work schemes
Finance
Calculator
US$
%
Total amount repayable . APR representative. Finance is subject to status. Terms and conditions apply.
Customer
Reviews
Alex
As my first drop bar bike with clips there was potential for disaster plus as a 130kg bloke I was concerned how the bike would cope. However the more rugged construction of the gravel bike has been a revelation with the slightly flared bars making for a really comfortable cycling experience.

Other than the absence of the 'climb hills like a pro' button it's an amazing bike really confident on descents taking poor surfaces with ease and no flex getting up out the saddle even with a lot of weight and force going through the drive train. Love the bike and Ribble as a supplier were brilliant and couldn't help enough when picking the bike up taking through all key maintenance and inspection points without patronising a relatively novice cyclist.
Robert Smith
I've put about 60 miles on my CGR in the first week and every mile has been an absolute joy. I live in Wisconsin where the roads are pretty rough, and this bike handles the bumps extremely well. The frame angle and saddle position are very comfortable for my 6'3" frame, even after riding for an hour or more I am still happy to keep going.

The service from Ribble has been incredible, I had a few questions and they were all answered extremely quickly. The bike arrived and was easily put together in less than an hour.

I will continue to recommend Ribble to all of my riding buddies, and anyone looking for a new bike.
