Ribble Ultra Tri Disc - Sport
Shimano 105 & Carbon Wheels

BBULTRDB004
From: US$4,057.09
This is a loan of US$4,868.51 with US$0.00 deposit.
Repayable by 36 monthly repayments of US$166.31.
Total amount repayable US$5,987.31.
14.9 APR representative.
Finance is subject to status. Terms and conditions apply.
Or from: US$166.31 a month
Also available on Cycle To Work schemes
An image of the Ribble Ultra Tri Disc - Sport Shimano 105 & Carbon Wheels
DEFY THE
AIR

The performance-tuned, race-bred Ultra Tri Disc has been engineered to meet the demands of today’s triathlete, with Advanced-grade carbon construction and class-leading aerodynamics. For this Sport edition, we have chosen the slick and intuitive shifting of Shimano’s 105 2x11 speed gear system with the additional stopping power of hydraulic disc brakes and a LEVEL 88/56 carbon fibre wheelset fitted with Continental Grand Prix GT tyres rounds off this competition-ready package.

  • Material

    Toray T1000/T800 Carbon Monocoque

  • Brakes

    Hydraulic Disc

  • Wheels

    LEVEL DB Sport Carbon 88/56

WHEELSET

Precision engineered for optimal aero efficiency and cross wind stability, the dissimilar rim profiles of the 56mm front and 88mm rear carbon wheelset improves airflow for a significant drag reduction. The wide internal rim profiles are optimised for wider tyres run at lower air pressures and the incredibly low-rolling resistance and enhanced grip that this offers. Fitted with Continental Grand Prix GT tyres which utilise a Black Chili and Vectran construction to produce a fast-rolling tyre with impressive puncture protection and grip.

GROUPSET

Shimano’s 105 gear system offers a gateway into the benefits of 11 speed shifting thanks to technology derived directly from their top-tier race series. With quick, smooth, and intuitive shifting, Shimano’s 105 gear system will inspire you to seek out new challenges. Powerful Rever hydraulic disc brakes afford you greater stopping power and control over the most technically demanding of courses.

HANDLEBARS

Ultra Tri base bars fitted with Zipp Vuka extensions offer plenty of adjustability for achieving the ideal position and reducing your frontal area for enhanced aerodynamic performance. A front hydration system mounted to the handlebars allows you to hydrate whilst crucially remaining in an aerodynamic position.

SADDLE

A multi-position carbon seat post provides extensive fore and aft adjustment to create a virtual seat tube angle of 76° to 79° and is fitted with a Selle Italia Watt saddle for less friction and more comfort without altering performance.

Custom Colour
Available

You decide the design, we create the bike. Be bold and bright or stealthy as you like. With millions of combinations, you can make a bike unique to you.

Just select customise after choosing your size.

Your Bike. Your Way
Size
Guide

To assist you in selecting the correct size simply find you height below. The graphic below illustrates our recommendations so you can be confident that the size you order will be correct.

X-Small
5' 0" - 5' 4"
153cm - 163cm
Small
5' 4" - 5' 7"
163cm - 170cm
Medium
5' 7" - 5' 10"
170cm - 178cm
Large
5' 10" - 6' 1"
178cm - 185cm
X-Large
6' 1" - 6' 4"
185cm - 193cm
View Full Sizing & Geometry
Sizing &
Geometry
Ribble Ultra Tri Disc - Sport
XS S M L XL
Rider Height 155 - 163cm
5'1" - 5'4"
163 - 170cm
5'4" - 5'7"
170 - 178cm
5'7" - 5'10"
178 - 185cm
5'10" - 6'1"
185 - 193cm
6'1" - 6'4"
A - Frame Size (mm) 480 500 520 540 560
B - Top Tube (mm) 474 501 523 544 566
C - Reach (mm) 372 399 415 431 447
D - Headtube (mm) 80 80 107 134 161.4
E- Stack (mm) 479 480 506 532 558
F - Fork Angle 72.5º 72.8º 72.8º 72.8º 73.8º
G - Wheelbase (mm) 929 954 978 1002 1027
H - Chainstay Length (mm) 387 387 387 387 387
I - Seat Tube Angle 76º - 79º 76º - 79º 76º - 79º 76º - 79º 76º - 79º
Available on
Cycle To Work

The Ribble Ultra Tri Disc - Sport is available to order on cycle to work schemes.

We accept all major cycle to work scheme vouchers.

Cyclescheme logos
Full
Specification
Groupset
Shimano 105 TT 2x11 speed Hydraulic Disc
Shifters - Shimano Dura Ace SL-BSR1 Bar End.
Brakes - REVER Triva Flat Mount Hydraulic TT.
Brake Levers - REVER Triva Hydraulic Disc TT.
Chainset - Shimano 105 R7000 50-34T.
Bottom Bracket - Ribble Press Fit PF30 68x46.
Cassette - Shimano 105 R7000 11-28T.
Chain - Shimano HG601 11-Speed.
Rotors - Shimano RT70 Centre Lock 140mm.
Front Derailleur - Shimano 105 R7000 Braze On.
Rear Derailleur - Shimano 105 R7000 Short Cage.
Wheelset
Wheels - LEVEL DB Sport Carbon 88mm Rear/56mm Front.
Tyres - Continental Grand Prix GT, 700x28c, Black.
Frameset
Frame - Toray T1000/T800 Carbon Fibre Monocoque.
Forks - Full Carbon Monocoque, Tapered Steerer.
Headset - Ultra TT, 1 1/8”- 1 3/8”, Black.
Finishing Kit
Bars - Ultra Tri Aero Bar, Black, 400mm.
Stem - Ultra Tri Alloy, Black, 31.8mm.
Extensions - ZIPP Vuka Alumina Race Alloy, 70°.
Bar Tape - LEVEL Embossed, Black.
Seatpost - Ultra Tri Carbon, Black.
Saddle - Selle Italia WATT, Black.
Extras
Top Tube Mounted Nutrition Box.
Seat Tube Mounted Storage Box.
Handlebar Mounted Hydration System.
Weight
Approximate Weight - 10.15kg/22.33lbs (medium).
